Author: Samir Jamil Shaikh
Project Type: Backend Automation (Python)
APIs Used: Gmail API, Google Sheets API

This project is a Python-based automation system that reads real unread emails from a Gmail inbox and logs them into a Google Sheet.
Each qualifying email is appended as a new row containing sender details, subject, timestamp, and plain-text content.

The system uses OAuth 2.0 authentication (Installed App flow) and ensures that no duplicate emails are logged, even if the script is run multiple times.

For every unread email in the Gmail Inbox, the script records the following fields in Google Sheets:

This diagram illustrates the end-to-end flow of the system, showing how unread emails are fetched from Gmail, processed by the Python automation layer, and appended to Google Sheets using Google APIs.

gmail-to-sheets/
├─ src/                     # Application source code
│  ├─ main.py               # Entry point
│  ├─ gmail_service.py      # Gmail API authentication & fetch logic
│  ├─ sheets_service.py     # Google Sheets integration
│  ├─ email_parser.py       # Email content extraction
│  └─ config.py             # Configurations (Sheet ID, scopes)
│
├─ credentials/             # OAuth files (ignored by git)
│  └─ credentials.json
│
├─ state/                   # Stores processed Gmail message IDs
│  └─ processed_ids.json
│
├─ proof/                   # Execution proof
│  ├─ gmail_inbox.png
│  ├─ google_sheet.png
│  └─ oauth_consent.png
│
├─ .gitignore
├─ requirements.txt
└─ README.md

python -m venv venv
venv\Scripts\activate

1. Create a Google Cloud project

2. Enable:

   • Gmail API
   • Google Sheets API

3. Configure OAuth Consent Screen:

   • User Type: External

   • Add your Gmail as a Test User

4. Create OAuth Client:

   • Application type: Desktop App

5. Download credentials.json and place it in:

   credentials/credentials.json

• Create a Google Sheet

• Copy the Spreadsheet ID from the URL

• Paste it into config.py

• Ensure the sheet name matches exactly

python src/main.py

On first run:

• Browser opens for OAuth

• Permissions are granted

• Token is stored locally

On subsequent runs:

• No OAuth prompt

• Only new emails are processed

This project uses OAuth 2.0 Installed App Flow:

• Suitable for local scripts

• No public redirect URLs required

• Tokens are stored locally (token.pickle)

• No service accounts are used

This approach is ideal for personal Gmail access and development/testing scenarios.

Duplicate emails are prevented using Gmail Message IDs:

• Each Gmail email has a unique immutable ID

• After processing an email, its ID is saved in: state/processed_ids.json

• On subsequent runs:

  • The script checks this file

  • Skips emails that were already processed

This ensures idempotent behavior.

State is persisted using a local JSON file: ["18c3a7f8a9d2babc", "18c3a7f8a9d2bbbb"]

This section demonstrates that the system was executed successfully in a real environment using a live Gmail account and an active Google Sheet.

All evidence is provided in the /proof directory and validates end-to-end functionality, authentication flow, and data persistence behavior.

File: proof/gmail_inbox.png

This screenshot shows the Gmail inbox before and after execution, highlighting unread emails that were processed by the automation.

Validated behavior:

• Only emails from the Inbox were considered
• Only unread emails were processed
• Emails were marked as read after successful logging
• No previously processed emails were re-read

File: proof/google_spread_sheet.png

This screenshot confirms that email data was correctly appended to the Google Sheet as new rows.

Validated behavior:

• Each email is logged as a single row
• Columns include sender, subject, timestamp, and content
• Existing rows remain unchanged
• No duplicate entries are created on re-execution

File: proof/oauth_consent.png

This screenshot captures the OAuth consent screen used during first-time authentication.

Validated behavior:

• OAuth 2.0 Installed App flow was used
• No API keys or service accounts were involved
• Access was granted explicitly by the user
• Tokens were stored locally and reused securely

To validate idempotent behavior, the script was executed multiple times without resetting state.

Observed result:

• No duplicate rows were added
• Only newly received emails were processed
• Previously processed emails were skipped based on stored state

This confirms correct implementation of state persistence and duplicate prevention logic.

The provided proof demonstrates that the automation:

• Operates on real production services (Gmail & Google Sheets)
• Authenticates securely using OAuth 2.0
• Maintains data integrity across executions
• Behaves predictably and safely when re-run

Understanding OAuth errors and access restrictions during development.

Added the developer Gmail account as a Test User and used OAuth Installed App flow instead of Web App flow.

This project demonstrates:

• Secure OAuth 2.0 integration

• API-driven automation

• State persistence

• Clean code organization

• Real-world backend problem solving
